H.265 8 HDD 64ch NVR

• H.265 Compression
• Support 64-ch input
• Up to 12MP Resolution Recording
• Incoming Bandwidth 640Mbps
• Outgoing Bandwidth 640Mbps

Category: Bright ( NVR )

• H.265 Compression
• Support 64-ch input
• Up to 12MP Resolution Recording
• Incoming Bandwidth 640Mbps
• Outgoing Bandwidth 640Mbps

Input
Video Input	64-ch
Max Resolution	12MP
Recording Bandwidth	Income 640 Mbps; Outcome 640 Mbps
Output
HDMI	HDMI 4 (1024768, 1280720, 12801024, 1440900, 19201080 , 25601440, 3840*2160/EDID）Async out
Audio Output	1
Decoding
Decoding Format	H.265+/H.265/H.264/M-JPEG
Recording Resolution	12MP/8MP/5MP/3MP/2MP(1080P)/1.3MP(960P)/
Recording Resolution	1.0MP(720P)
Synchronous Playback	Max 16CH playback
Hard Disk
SATA	8 SATA interfaces for 8 HDDs
Capacity	upto 18TB (Enterprise-Class) each SATA
eSATA Interface	1 SATA interface
Array Type	RAID0, RAID1, RAID5, RAID6, RAID10
External Interface
Network Interface	2×RJ45 self-adaptive 10/100/1000 Mbps network interfaces,
USB Interface	1×USB 2.0, 2×USB 3.0
Serial Interface	1×RS485,
Alarm In/Out	16/4
General
Language	English
Operating Conditions	-10℃～55℃, 0%~95% RH
Power Supply	DC 12V/5A,
Consumption (without HDD)	≤8W (without HDD)
Dimensions	44046089mm
